TCM 系列计量式色母混合机适用于新料、次料、色母或添加剂等的自动比例混合。该系列机型使用直流无刷式马达 , 依据预选设定的比例混合 , 透过触控屏微电脑控制系统设定的条件自动转换成转速直接驱动精密螺杆挤出原料 , 其误差值不高于±1%。该产品的马达减速比分为 30:1 及 100:1 两种 , 螺杆直径区分为 12、14、16mm 三种 , 可演变出六种机型提供0.1~32kg/h 的不同输出量供客户选择。另有双色色母机 , 可依客户需求搭配任意两台色母机合并使用。
TCM | 系列
The TCM series metering masterbatch mixer is suitable for automatic proportional mixing of new materials, secondary materials, master?batch or additives, etc. This series of models uses a DC brushless motor, which is mixed according to a pre-selected proportion. The conditions set by the touch screen microcomputer control system are automatically converted into rotational speed to directly drive the precision screw extrusion of raw materials, with an error value not exceeding ± 1%. The motor reduction ratio of this product is divided into two types: 30:1 and 100:1, and the screw diameter is divided into three types: 12, 14, and 16mm. It can evolve into six models and provide different output quantities of 0.1-32kg/h for customers to choose from. There is also a dual color master machine, which can be combined with any two color master machines according to customer needs.
使用直流无刷式马达 , 无需保养 ;
具备数据永久记忆及存储功能 ;
采用微电脑式控制 , 智能化精确计算 ;
可同时满足外部信号输入的要求 ;
螺杆采用镀铬处理 , 经久耐用 ;
模组式的装配结构 , 拆装方便 , 易于清理及互换 ;
单色色母机机型可选配搅拌器 , 混料均匀 ;
主料斗为双色色母机的标准配备 , 单色色母机可选配 ;
Brushless DC motor, no maintenance;
With data permanent memory and storage function;
Microcomputer control, intelligent and accurate calculation;
Can meet the requirements of external signal input at the same time;
The screw adopts chrome plating treatment, durable;
Modular assembly structure, easy to disassemble and assemble, easy to clean and interchange;
Single color machine model can be optional agitator, uniform mixing;
The main hopper is standard equipped with two color mother machine, and single color mother machine is optional
|
|
